730 ton Van Dorn - Installed new in 2004 - Model 730CC4300 - 89.6 oz. shot
Clamp Tonnage | :::: | 730 tons US |
Tie Bar Distance | :::: | 42.3" x 42.3" |
Platen Size | :::: | 57" x 57" |
Mold Thickness | :::: | 13.7"min / 40.7"max |
Clamp Stroke | :::: | 57" |
Daylight | :::: | 70.8" |
Shot Size | :::: | 89.6 oz. |
Equipped With: |
NC-5 Controller Dual Corepull Valve Gates |
